| SYSTEM |
| PROCESSOR |
Intel® Core™ i Dual Core up to 3.4GHz Processor Intel® Celeron® 3955U Dual Core 2.0GHz Processor |
| OPERATING SYSTEM |
Windows® 10 IoT Enerprise 64bit, Windows® 7 Embedded 32/64bit |
| MEMORY |
DDR3 SODIMM Socket x 1, up to 8 GB |
| STORAGE |
M.2 (NGFF) SSD, up to 256 GB |
| DISPLAY |
11.6" TFT-LCD/ 16:9, with Projected Capacitive Multi-Touch screen |
| I/O PORT |
DC-in Jack x 1, USB 3.0 x 1 (Type A), USB 2.0 x 2 (Type A), RJ45 x 1, COM
x 1, HDMI x 1, Micro SD Card Slot x 1, 3.5-mm stereo headphone jack x 1, Built-in Speaker & Microphone SIM Card Slot x 1, Barcode Scanner (Optional) |
| COMMUNICATION |
Bluetooth v4.1, Wi-Fi (802.11 b/g/n), Front-facing NFC/ RFID (13.56MHz), 3G (Optional) |
| NAVIGATION |
GPS, Glonass |
| WWAN (OPTIONAL) |
3G: WCDMA |
| CAMERA |
2 MP front camera, 5 MP auto-focus rear camera with flash |
| SENSOR |
G-sensor, E-Compass, Gyroscope, Light-sensor |
| EXPANSION SLOT |
Docking; GPS/WLAN Pass-though via Docking |
| BARCODE SCANNER (OPTIONAL) |
1D Scanner support CMOS engine (Optional), 2D Scanner support LED engine |
| HF RFID (OPTIONAL) |
Front-facing HF RFID based on 13.56MHz compatible with NFC |
| PHYSICAL KEY |
F0 or Windows (Windows Start Key), F1(Ctrl+Alt+Del & Barcode Scanner Trigger), F2(Touch Mode Switch), F3(PrtSc/printscreen), Volume Up, Volume Down |
| MECHANICAL |
| COLOR |
Gray & Black |
| DIMENSIONS (W X H X D) |
12.36" x 7.87" x 0.96" (310.4mm x 200mm x 24.5mm) |
| GROSS WEIGHT |
3.3 lbs (1.5 kg) |
| ENVIRONMENTAL |
| OPERATING TEMPERATURE |
-4°F ~ 140°F (-20°C ~ 60°C) |
| STORAGE TEMPERATURE |
-67°F ~ 158°F (-55°C ~ 70°C) |
| HUMIDITY |
50°C; 5% ~ 90% R/H; 120 hours, non-condensing |
| ENVIRONMENTAL SEALING |
IP65 |
| VIBRATION |
MIL-STD-810G Method 514.6 Procedure I, Cat. 24, Fig. 514.6E-1 & E-2 |
| DROP |
MIL-STD-810G Method 516.6 Procedure IV
- Height of Drop: 122cm (48 inch; 4ft),
- Number of Drop: 26 times, - Floor: Twoinch plywood backed by concrete,
- For all surfaces, edges and corners |
| ESD |
Air charge: +/- 8KV, Contact charge: +/- 4KV |
| CERTIFICATIONS AND STANDARDS |
UL: UL60950-1, CE/LVD: EN60950-1, FCC, CE |
| POWER SUPPLY |
| AC ADAPTER |
AC 100~240V, 50~60Hz ; DC 19V/3.42A (65W) |
| DISPLAY |
| LCD |
11.6" TFT-LCD/ 16:9, with LED backlight |
| RESOLUTION |
1920 x 1080 pixel |
| MAX. COLORS |
16.7M |
| DOT SIZE |
0.117 x 0.117(H) |
| BRIGHTNESS |
1000 nits; 300 nits (Optional) |
| VIEWING ANGLE |
Horizontal: 178° (Typ.), Vertical: 178° (Typ.) |
| TOUCH SCREEN |
| TOUCHSCREEN TYPE |
Projected capacitive multi-touch screen (PCT); Gloves/Finger Switchable by F2 |
| LIGHT TRANSMISSION |
Min 87% (ASTM D1003; Wavelength = 550nm) |
